Isostatic Graphite
Isostatic graphite is a type of graphite produced using the isostatic pressing technique.In this process, graphite paste is subjected to equal pressure from all directions, resulting in a product with isotropic properties and high structural uniformity.
These characteristics, combined with the material’s high purity, lead to outstanding physical strength, thermal and electrical conductivity, a low coefficient of thermal expansion, and excellent resistance to corrosion and rapid environmental fluctuations.
Thanks to these properties, isostatic graphite is widely used in demanding industries such as nuclear reactors,semiconductors, and aerospace, where consistent high performance is essential.
Feature
- High purity and High density
- Isotropic and uniformity
- High physical strength
- Low electrical resistivity
- Excellent thermal conductivity
- Low Coefficient of thermal expansion
- Stability in corrosive and rapidly changing environment
Application
- Semiconductor industry
- Reactor industry
- Aerospace industry
- Photovoltaic industry
- Metallurgy industry
- Machinery industry
Specification
| Grade | Density（g/cm³） | Ash Content（ppm） | Resistance（μΩm） | Shore Hardness | Flexural Strength (MPa) | Compressive Strength (MPa) |
| GDT-01 | 1.68 | 800 | 12 | 35 | 25 | 50 |
| GDT-02 | 1.75 | 700 | 13 | 46 | 34 | 66 |
| GDT-03 | 1.78 | 800 | 10 | 50 | 40 | 80 |
| GDT-04 | 1.8 | 600 | 11 | 52 | 43 | 81 |
| GDT-05 | 1.82 | 600 | 13 | 64 | 51 | 103 |
- Typical data provided for reference only; not guaranteed.
- Customized specifications available upon request. Please contact us for more information.
